2x subwoofer, 2x 2-way top, 2x distance tube, 2x power amp, flightcase and 8x connection cables
OMNITRONIC PAS-151 MK3 Subwoofer
Passive 15" bassreflex subwoofer with 700 W RMS, 8 ohms
- Rugged Pro PA subwoofer
- 38 cm (15") bass speaker
- Parallel Speaker connectors
- Rugged multiplex cabinet
- Scratch-resistant lacquer surface
- Metal handlebars
- Impact-resistant steel grille with acoustic foam
- Flange for mounting top speakers
- With Wheels optional
OMNITRONIC PAS-212 MK3 2-Way Top
Passive speaker with 12" woofer, 1" driver and 300 W RMS
- Rugged full-range top speaker, qualified for suspension
- Trapezoidal, multi-functional multiplex cabinet with scratch-resistant lacquer surface
- 2-way bass-reflex system with 30 cm woofer (8 cm voice coil)
- 2.5 cm compression driver with ferrite magnet (3.8 cm voice coil with polymer diaphragm)
- Parallel Speaker connections
- Optimized for combination with PAS subwoofers
- Dual flange with 0° and 5° tilt angle enables flexible positioning
- M8 threaded inserts for suspended installation
- Protective grille and recessed aluminum handlebars
- Applications: standing, on a subwoofer or speaker stand, suspended
OMNITRONIC Distance Tube Subwoofer/Satellite with Crank
Variable distance tube (M20 thread), height adjustable via crank 80-110 cm
- Connecting tube for satellite systems
- Height adjustable via crank 80-110 cm
- M20 thread
- Powder-coated steel version
- Color: black
OMNITRONIC XDA-1002 Class D Amplifier
Stereo PA amplifier with SMPS, 2 x 510 W / 4 ohms, 2 x 300 W / 8 ohms
- Stereo PA amplifier with class D circuitry
- Low weight and height due to integrated switch mode power supply
- Speaker switch-on delay and auto limiters
- 2 operating modes can be selected (stereo or bridged)
- 2 level controls
- LEDs for activated protective circuit, limiter, signal, and power
- Complete protection set against short-circuit, overheat, DC voltage, power on/off transients, soft start
- Ground lift switch against humming
- Electronically balanced inputs via XLR mounting jacks with feed-through output
- Speaker outputs via lockable speaker jacks
- The device is cooled by cooling fan
- (19") 48.3 cm rack installation 1 U
OMNITRONIC XDA-2402 Class D Amplifier
Stereo PA amplifier with SMPS, 2 x 1200 W / 4 ohms, 2 x 880 W / 8 ohms
- Stereo PA amplifier with class D circuitry
- Low weight and height due to integrated switch mode power supply
- Speaker switch-on delay and auto limiters
- 2 level controls
- LEDs for activated protective circuit, limiter, signal, and power
- Complete protection set against short-circuit, overheat, DC voltage, power on/off transients, soft start
- Ground lift switch against humming
- Electronically balanced inputs via XLR mounting jacks with feed-through output
- Speaker outputs via lockable speaker jacks
- The device is cooled by cooling fan
- (19") 48.3 cm rack installation 1 U
OMNITRONIC DXO-24E Digital Controller
Digital stereo active crossover with 2 inputs and 4 outputs, incl. software
- Flexible routing configurations for all standard mono and stereo output operating modes
- 2 analog inputs and 4 analog outputs (XLR)
- Active frequency filter types (Bessel, Butterworth and Linkwitz-Riley) with slopes up to 24 dB/octave split up the audio signal into different frequency bands
- Incl. software editor (for PC and Mac) for remote control via computer through USB interface: store, transfer, and manage your presets
- Up to 30 user presets storable in the device via software
- Alphanumeric LCD screen with 2 lines of 16 characters each
- Input sensitivity digitally adjustable
- Inputs and outputs with 4-digit LED level meter as well as clip and limit LED indicator
- Mute switch with LED indicator per output
- 7-band parametric EQ per output
- Up to 7 ms signal delay adjustable for the outputs
- Output limiter with adjustable limits and automatic attack and release settings as overload protection for your amplifying system
- Switchable phase
- Lock function for protecting the program settings
- Windows XP, Vista, 7, 10 and Mac OS X 10.5.8 and better
- Digital signal processor
- The device can be connected via USB to the PC in connection with DXO Software
The firmware can be updated via the PC connection - (19") 48.3 cm rack installation 1 U
ROADINGER Amplifier Rack PR-2, 4U, 47cm deep
Flightcase for 483 mm devices (19")
- Profile rails with 4 U mounting facility for 483 mm units (19"), e.g. PA amplifiers, power packs, additional equipment
- Front and rear rack rails
- 2 removable covers (double-door version)
- Max. depth 420 mm (plus 90 mm per cover)
- 2 wooden slide rails on the bottom
- Delivery includes mounting screws
- Available in different height units (1 U = 44 mm)
- High-quality workmanship with plywood glued 7 mm, black, laminated
- Aluminum profile frames 30mm with rounded edges
- 2 hinged, chromium plated case handles
- 4 high-quality butterfly locks
- With profile rails suitable for (19") approx. 48 cm units
- 4 U
PSSO Speaker cable Speakon 2x2.5 10m bk
High-quality speaker cable
- With Neutrik plugs from Liechtenstein
- Cable from German production
- 2-pole speaker cable
- With Neutrik Speakon cable plugs
- Cable cross-section: 2.5 mm²
- Cable length: 10 m
- Cable diameter: 8 mm
- Weight: 1 kg
- NEUTRIK
PSSO XLR cable 3pin 1m bk Neutrik
Reliable microphone cable
- High quality connection for microphones etc.
- High conductivity
- Slim and short construction
- NEUTRIK
- Made in Germany
Weight: | 142,67 kg |
OMNITRONIC PAS-151 MK3 Subwoofer | |
Rated power: | 700 W RMS |
Program power: | 1400 W |
Frequency range: | 40 - 200 Hz |
Sensitivity: | 97 dB (1W/1m) |
Max. SPL: | 127 dB |
Impedance: | 8 ohms |
Connections: | Input: speakers via 2 x speaker built-in socket (F) |
Speakers: | 1 x woofer (15") approx. 38 cm with ferrit magnet Basket material: aluminum Voice coil lows (4") approx. 10 cm |
Type of speaker: | Subwoofer |
Type: | Vented |
Transport aid: | Wheels optional |
Material: | Birch multiplex |
Color: | Black, painted |
Dimensions: | Width: 46 cm Depth: 56 cm Height: 52 cm |
Weight: | 31,25 kg |
OMNITRONIC PAS-212 MK3 2-Way Top | |
Rated power: | 300 W RMS |
Program power: | 600 W |
Frequency range: | 60 - 20000 Hz |
Sensitivity: | 98 dB (1W/1m) |
Max. SPL: | 126 dB |
Dispersion angle: | 90° x 60° |
Crossover frequency: | 3000 Hz |
Impedance: | 8 ohms |
Attachment system: | Ø 35mm variable tilt |
Flying points: | 4 x M10 thread; 6 x M8 thread |
Connections: | Input: speakers via 2 x speaker built-in socket (F) |
Speakers: | 1 x compression tweeter highs (1") approx. 2,5 cm Basket material: aluminum Voice coil compression tweeter highs (1.5") approx. 4 cm Horn vent (1") approx. 2,5 cm 1 x woofer (12") approx. 30 cm with ferrit magnet Voice coil lows (3") approx. 8 cm |
Type of speaker: | Compact cabinet speaker |
Material: | Birch multiplex |
Color: | Black, painted |
Dimensions: | Width: 39 cm Depth: 61,5 cm Height: 38 cm |
Weight: | 20,60 kg |
OMNITRONIC Distance Tube Subwoofer/Satellite with Crank | |
Maximum carrying capacity: | 35 kg |
Height: | Maximum: 110 cm Minimum: 80 cm |
Attachment system: | Ø 35mm |
Type (general stands): | Distance tube |
Color: | Black |
Weight: | 2,80 kg |
OMNITRONIC Swing Bracket for PAS-212 MK3 | |
Weight: | 3,75 kg |
OMNITRONIC XDA-1002 Class D Amplifier | |
Power supply: | 100-240 V AC, 50/60 Hz |
Power consumption: | 210 W 1/8 power |
Output power: | 2 x 300 W RMS (8 ohms) 2 x 510 W RMS (4 ohms) 1000 W RMS bridged (8 ohms) |
Power connection: | Mains input P-Con (blue), mounting version power supply cord with safety plug (provided) |
Frequency range: | 30 - 20000 Hz |
S/N ratio: | >100 dB |
THD: | <0,02 % at 1 kHz |
Cooling: | Cooling fan |
Impedance: | Input 20 kOhm , bal. Input 10 kOhm , unbal. |
Gain: | 36 dB |
Circuitry: | Class D |
Control elements: | Power switch, level control per channel, mode switch (stereo/bridged), groundlift selector |
Controls: | Short-circuit; overheat; DC voltage; power on/off transients; softstart; power on/off transient; limiter |
Status LED: | Power, signal, protect, limit |
Connections: | Input: line via 2 x 3-pin XLR Link: line via 2 x 3-pin XLR Output: speakers via 2 x speaker built-in socket (F) |
Input sensitivity: | 1,25 V |
Housing design: | (19") 48.3 cm rack installation 1 U |
Dimensions: | Width: 48,3 cm Depth: 24 cm Height: 4,45 cm |
Weight: | 4,03 kg |
OMNITRONIC XDA-2402 Class D Amplifier | |
Power supply: | 100-240 V AC, 50/60 Hz |
Power consumption: | 465 W 1/8 power |
Output power: | 2 x 880 W RMS (8 ohms) 2 x 1200 W RMS (4 ohms) |
Power connection: | Mains input P-Con (blue), mounting version power supply cord with safety plug (provided) |
Frequency range: | 30 - 20000 Hz |
S/N ratio: | >100 dB |
THD: | <0,02 % at 1 kHz |
Cooling: | Cooling fan |
Impedance: | Input 20 kOhm , bal. Input 10 kOhm , unbal. |
Circuitry: | Class D |
Control elements: | Power switch, level control per channel, groundlift selector |
Controls: | Short-circuit; overheat; DC voltage; power on/off transients; softstart; power on/off transient; limiter |
Status LED: | Power, signal, limit, protect |
Connections: | Input: line via 2 x 3-pin XLR Link: line via 2 x 3-pin XLR Output: speakers via 2 x speaker built-in socket (F) |
Input sensitivity: | 1,25 V |
Housing design: | (19") 48.3 cm rack installation 1 U |
Dimensions: | Width: 48,3 cm Depth: 35,5 cm Height: 4,45 cm |
Weight: | 6,40 kg |
OMNITRONIC DXO-24E Digital Controller | |
Power supply: | 100-240 V AC, 50/60 Hz 6 V DC 800 mA |
Power connection: | Mains input Coaxial power connector (M) power supply cord with AC adapter (provided) |
Frequency range: | 10 - 30000 Hz |
THD: | <0,005 % at 1 kHz |
DSP: | Digital signal processor |
Crossover frequency: | 20-20000 Hz |
Impedance: | Input 10 kOhm Output 50 Ohm |
Gain: | Output: -50 dB to +12 dB |
Filter: | Linkwitz-Riley; Butterworth; Bessel; 6db/oct; 12db/oct; 18db/oct; 24db/oct |
Delay: | 0 - 5 ms |
Dynamic range: | Input: 114 dB Output: 110 dB |
Sample rate: | 67 kHz |
Connections: | Input: line via 2 x 3-pin XLR Output: line via 4 x 3-pin XLR |
Max. level: | Input: +22 dBu Output: +9 dBu |
USB port: | Typ B |
PC connect: | DXO Software via USB, firmware can be updated |
Housing design: | (19") 48.3 cm rack installation 1 U |
Dimensions: | Width: 48,3 cm Depth: 12,8 cm Height: 4,45 cm |
Weight: | 1,60 kg |
ROADINGER Amplifier Rack PR-2, 4U, 47cm deep | |
Maximum load: | 25 kg |
Aluminum profile frames: | 30 mm |
Case handles: | 2 pc/pcs |
Lock: | Butterfly lock: 4 pc/pcs |
Material: | Plywood glued, 7 mm |
Color: | Black, laminated |
Front panel width: | (19") approx. 48 cm |
Mounting height: | Approx. 18 cm (4 U) |
Mounting depth: | 420 mm |
Housing design: | 4 U |
Dimensions: | Width: 54,5 cm Depth: 64 cm Height: 22 cm |
Weight: | 9,40 kg |
PSSO Speaker cable Speakon 2x2.5 10m bk | |
Cable construction: | 2 x 2,5 mm² Loudspeaker cable |
Cable length: | 10 m |
Plug A: | 1 x 2-pin SpeakON (M) |
Plug B: | 1 x 2-pin SpeakON (M) |
Use of brands: | NEUTRIK |
Color: | Black |
Weight: | 1 kg |
PSSO XLR cable 3pin 1m bk Neutrik | |
Cable construction: | 2 x 0,22 mm² Audio cable |
Cable length: | 1 m |
Plug A: | 1 x 3-pin XLR (M) |
Plug B: | 1 x 3-pin XLR (F) |
Use of brands: | NEUTRIK |
Color: | Black |
Weight: | 110 g |
