Complete DMX LED lighting system with rechargeable battery pack
- Crossbar with integrated DMX control unit and stand sleeve
- Ultra-light, ideally suited for mobile use
- Ideal for bands, mobile DJs and stages
- Suited for installation on a speaker stand (not included) or truss
- Comes pre-assembled with practical transport bag
- Operation via mains connection or built-in rechargeable lithium-ion battery with up to 20 hours operating time
- Integrated automatic charging of the battery with indicator
- Energy-saving mode
- 4 high-power 8 W LEDs (4in1) per spot provide for an exquisite RGBW color mix
- Strobe effect with 4 white 1 W LEDs
- Movable and tiltable spotlights
- Each spot can be individually controlled via DMX
- Built-in auto and music show programs
- Direct color selection for 20 preset colors
- Stepless color blend, color change, color fade, dimmer and strobe effect
- Supports QuickDMX - the wireless DMX system from Eurolite
- Built-in phantom-powered USB port for QuickDMX, CRMX and WDMX receivers (optional)
- Control panel with LED display for easy configuration
- Convenient wireless control via included IR remote control
- Mains input and output for power linking up to 8 units
- LED: Spot 4 x high-power 8 W 4in1 QCL RGBW (homogenous color mix)
- LED: Strobe effect 4 x separate controlling each with 4 x high-power 1 W cold white (CW)
- Can be operated in 3; 4; 8; 21 CH mode
- The device is cooled by passive convection
- Controlling by stand-alone; Sound to light via Microphone; DMX; IR remote control (provided); Master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
- Preprogrammed in EASY SHOW
- Flicker-free projection
| Power supply: | 100-240 V AC, 50/60 Hz |
| IP classification: | IP20 |
| Power connection: | Battery/battery pack
Mains input IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Power output: | IEC connector (F) mounting version |
| Fuse: | T 1 A Fuse replaceable |
| Battery pack type: | 1 x lithium ion 22,2 V, 4400 mAh, 97,68 Wh |
| Battery pack: | Battery operation up to 20h depending on program used
Recharging time 5h |
| Lamp type: | LED lamp |
| LED: | Spot 4 x high-power 8 W 4in1 QCL RGBW (homogenous color mix)
Strobe effect 4 x high-power 1 W cold white (CW) |
| Flash rate: | 0 - 20 Hz |
| DMX channels: | 3; 4; 8; 21 |
| DMX input: | 3-pin XLR (M) mounting version |
| DMX output: | 3-pin XLR (F) mounting version |
| Cooling: | Passive convection |
| Control: | Stand-alone; Sound to light via Microphone; DMX; IR remote control (provided); Master/slave function; EASY SHOW; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional) |
| Beam angle: | 9° |
| Beam angle (1/2 peak): | 9° |
| Housing color: | Black |
| Display type: | 4 digits 7-segment LED display |
| Dimensions: | Width: 61 cm
Depth: 14,5 cm
Height: 27,4 cm |
| Weight: | 5,90 kg |
| Noise classification: | Class 0 (no noise at all) |
| Remote control |
| Battery: | 1 x Button cell 3.0 V CR2025 lithium manganese built-in |
| Legal specifications |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
