The AKKU TL-3 TCL Trusslight QuickDMX is a spotlight equipped with 3 bright 3-watt RGB LEDs (3in1) for lighting within trussing. It is wireless and battery-run (battery life 16 hours) and its small size makes it a great fit for many 3- and 4-point trussing systems. Furthermore, this device is equipped with a built-in QuickDMX transceiver for wireless transmission of DMX512 signals.You can choose from a variety of different functions such as static colors, continuous RGB color mixture, internal programs, dimmer effects as well as strobe effects with adjustable speed. The device can either be controlled via DMX or the supplied wireless remote control (Eurolite IR-13). All of these features make the AKKU TL-3 TCL the perfect choice for booth construction, stages and any kind of truss.
Spot for lighting within trussing, 3 x 3 W 3in1 LED, QuickDMX transceiver
- Compact and bright - ideal as truss light
- 3 high-power 3 W RGB LEDs (4in1)
- Battery operation up to 16 hours
- Ideal for booth construction, stages and anywhere trussing is used
- Ideal for ALUTRUSS DECOLOCK DQ3 3-point system
- With integrated QuickDMX receiver for the wireless transmission of DMX512 signals
- Stepless color blend, color change, dimmer and strobe effect
- Dimmer speed (step response) adjustable
- Addressing and setting via control board with LCD
- Convenient wireless control via included IR remote control
- Threaded inserts for suspended installation
- Mains input and output for power linking up to 8 units
- LED: 3 x high-power 3 W 3in1 TCL RGB (homogenous color mix)
- Can be operated in 3; 5; 8 CH mode
- The device is cooled by passive convection
- Controlling by DMX; stand-alone; QuickDMX built-in; IR remote control; Sound to light via Microphone
- Preprogrammed in Light´J; LED PC-Control 512; EASY SHOW; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE
- Flicker-free projection
- For application areas such as: Wedding/gala; Small lender
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 25 W |
| IP classification: | IP20 |
| Protection class: | Class I |
| Power connection: | Battery/battery pack
Mains input IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Cable length: | Approx. 1,2 m |
| Power output: | 1 x IEC connector (F) mounting version |
| Battery pack type: | 1 x lithium ion 11,1 V, 4400 mAh, 48,84 Wh |
| Battery pack: | Battery operation up to 16h depending on program used
Recharging time 3h |
| Lamp type: | LED lamp |
| LED: | 3 x high-power 3 W 3in1 TCL RGB (homogenous color mix) |
| Flash rate: | 0 - 23 Hz |
| DMX channels: | 3; 5; 8 |
| DMX input: | 1 x 3-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version |
| Cooling: | Passive convection |
| Control: | DMX; stand-alone; QuickDMX built-in; IR remote control; Sound to light via Microphone; Light´J; LED PC-Control 512; EASY SHOW; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE |
| Beam angle: | 11° |
| Beam angle (1/2 peak): | 11° |
| Beam angle (1/10 peak): | 24° |
| Housing color: | Black |
| Display type: | LCD display |
| Carrier frequency: | 2,4 GHz |
| Dimensions: | Width: 12,1 cm
Depth: 10,8 cm
Height: 14,5 cm |
| Weight: | 1,27 kg |
| Noise classification: | Class 0 (no noise at all) |
| Remote control |
| Battery: | 1 x Button cell 3.0 V CR2032 lithium manganese built-in |
| Legal specifications |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
