ML spot with RGBAW+UV LED (6in1) and RGB SMD ring
- One high-power 100 W LED (6in1) for RGBAW+UV color mixing and a LED ring with 32 RGB SMD LEDs
- Stepless color blend, color change, preset colors, dimmer and strobe effect
- Adjustable white balance
- LED ring with RGB color mixture, dimmer, color presets and color changes
- SMD ring and COB spot separately controllable
- Dimmer speed (step response) adjustable
- Stand-alone, master/slave and DMX mode
- Color presets can be called up via DMX controller
- Control panel with LED display for easy configuration
- Additional bracket for floor use
- Swivel mounting brackets
- With color filter frame
- Optional barndoors available
- LED: Ring 32 x SMD 0,2 W 3in1 TCL RGB
- LED: 1 x COB (chip-on-board) 100 W 6in1 HCL RGBWA/UV (homogenous color mix)
- Can be operated in 3 (HSV hue/saturation/value); 5; 6; 8; 9; 10; 14 CH mode
- The device is cooled by cooling fan
- Controlling by DMX; Sound to light via Microphone
- Preprogrammed in Light´J
- Flicker-free projection
- Effect: Strobe effect; UV effect
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 100 W |
| IP classification: | IP20 |
| Protection class: | Class I |
| Power connection: | Fixed power supply cord with safety plug |
| Cable length: | Approx. 1,2 m |
| Lamp type: | LED lamp |
| LED: | Ring 32 x SMD 0,2 W 3in1 TCL RGB
1 x COB (chip-on-board) 100 W 6in1 HCL RGBWA/UV (homogenous color mix) |
| Flash rate: | 0 - 17 Hz |
| DMX channels: | 3 (HSV hue/saturation/value); 5; 6; 8; 9; 10; 14 |
| DMX input: | 3-pin XLR (M) mounting version |
| DMX output: | 3-pin XLR (F) mounting version |
| Cooling: | Cooling fan |
| Control: | DMX; Sound to light via Microphone; Light´J |
| Beam angle: | 35° |
| Beam angle (1/2 peak): | 35° |
| Beam angle (1/10 peak): | 76° |
| Housing color: | Black |
| Display type: | 4 digits 14-segment LED display |
| Dimensions: | Width: 29 cm
Depth: 25,5 cm
Height: 32 cm |
| Weight: | 3,55 kg |
| Legal specifications |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
