Active 8" PA speaker with DSP presets, limiter, 210 W RMS
- Active PA speaker system for touring applications and permanent installations
- 2-way bassreflex enclosure with 20 cm woofer and 2.5 cm compression driver
- DSP-controlled class D amplifier with 210 watts power
- 3 EQ presets with indicators (DJ, monitor, flat)
- Switchable low cut (120 Hz, 90 Hz)
- Switch-on delay and limiter for overload protection
- Master control, limit, signal and power LED
- Balanced signal input XLR/6.3 mm jack, switchable mic/line
- XLR output for linking further active speaker systems
- Optimized for combination with PAS subwoofers
- Trapezoidal, multi-functional multiplex cabinet with monitor shape
- Scratch-resistant lacquer surface
- Carrying handles
- Impact-resistant steel grille with acoustic foam
- Dual flange with 0° and 5° tilt angle enables flexible positioning
- M8/M10 threaded inserts for suspended installation
- Applications: standing, as monitor, on a subwoofer or speaker stand, suspended
- Digital signal processor
| Power supply: |
230 V AC, 50 Hz |
| Power consumption: |
300 W |
| Output power: |
210 W RMS |
| Power connection: |
Mains input IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Frequency range: |
75 - 20000 Hz |
| Max. SPL: |
118 dB |
| DSP: |
Digital signal processor |
| Dispersion angle: |
90° x 60° |
| Attachment system: |
Ø 35mm variable tilt |
| Flying points: |
5 x M8 thread; 4 x M10 thread |
| Circuitry: |
Class D |
| Connections: |
Input: 3-pin XLR/6.35mm jack (F) combination socket (mounting version)
Link: 3-pin XLR |
| Input channels: |
1 x mono with Mic-line switch via XLR, channel control via Rotary dial |
| Speakers: |
1 x compression tweeter highs (1") approx. 2,5 cm with ferrit magnet
Basket material: aluminum
Voice coil compression tweeter highs (1.5") approx. 4 cm
Horn vent (1") approx. 2,5 cm
1 x woofer (8") approx. 20 cm
Voice coil lows (2") approx. 5 cm |
| Type of speaker: |
Compact cabinet speaker |
| Material: |
Birch multiplex |
| Color: |
Black, painted |
| Dimensions: |
Width: 27 cm
Depth: 46 cm
Height: 26,8 cm |
| Weight: |
11,70 kg |
