DMX controlled surface light with 240 cold white and 240 warm white LEDs
- Variable color temperature 3200-5600 K
- High-grade surface light with 480 super bright, white LEDs
- Ideal for photography, film, stage and trade fair lighting
- Energy-saving, durable and environmentally friendly
- Milky diffuser provides a homogeneous and soft continuous light
- 4 barn doors to avoid blinding the audience and for protection during transport
- Steplessly dimmable
- 4 dimmer speeds selectable
- Control panel with LC display for easy configuration
- Master/slave function
- Strobe effect 0-20 Hz
- Slim, rugged metal housing
- Swivel mounting bracket
- Comfortable carrying handle
- Stand or truss installation
- Mains input and output for power linking up to 8 units
- LED: 480 x SMD 0,5 W CW/WW (homogenous color mix)
- Can be operated in 5 CH mode
- The device is cooled by passive convection
- Controlling by DMX
- Preprogrammed in Light´J
- Flicker-free projection
- Very high color rendering index (CRI)
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 205 W |
| IP classification: | IP20 |
| Power connection: | P-Con (blue), mounting version power supply cord with safety plug (provided) |
| Power output: | 1 x P-Con (gray), mounting version |
| Lamp type: | LED lamp |
| LED: | 480 x SMD 0,5 W CW/WW (homogenous color mix) |
| Color temperature: | 3200K - 5600K adjustable |
| DMX channels: | 5 |
| DMX input: | 3-pin XLR (M) mounting version |
| DMX output: | 3-pin XLR (F) mounting version |
| Cooling: | Passive convection |
| Control: | DMX; Light´J |
| Beam angle: | 120° |
| Beam angle (1/2 peak): | 120° |
| Color rendering index (CRI) more than: | 95 Ra |
| Illuminance in Lux (lx): | Cold white (CW) 3m: 398 lx, 6m: 119 lx
Warm white (WW) 3m: 391 lx, 6m: 117 lx
All 3m: 787 lx, 6m: 234 lx |
| Luminous flux: | 17470 lm |
| Housing color: | Black |
| Display type: | LCD display |
| Dimensions: | Width: 64 cm
Depth: 12,5 cm
Height: 33 cm |
| Weight: | 12,60 kg |
| Noise classification: | Class 0 (no noise at all) |
| Legal specifications |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
| Energy efficiency class (A - G): | F |
