DMX controlled surface light with 192 LEDs each in cold and warm white, QuickDMX port, diffuser and barn doors
- High-grade surface light with 384 super bright, white LEDs
- Variable color temperature 2700-5700 K
- 69 preset color temperatures
- Ideal for photography, film, stage and trade fair lighting
- Energy-saving, durable and environmentally friendly
- Milky diffuser provides a homogeneous and soft continuous light
- 4 barn doors to avoid blinding the audience and for protection during transport
- Steplessly dimmable
- Supports QuickDMX - the wireless DMX system from Eurolite
- Built-in phantom-powered USB port for QuickDMX, CRMX and WDMX receivers (optional)
- Control panel with LC display for easy configuration
- Color temperature and brightness manually adjustable via wheel encoders
- Master/slave function
- Strobe effect 0-20 Hz
- Slim, rugged metal housing
- Swivel mounting bracket
- Additional rubber feet protect the device when positioned on the floor
- Stand or truss installation
- Mains input and output for power linking up to 8 units
- LED: 192 x SMD 5730 0,5 W cold white (CW)
- LED: 192 x SMD 5730 0,5 W warm white (WW)
- Can be operated in 2-1; 2-2; 3-1; 3-2; 4 CH mode
- The device is cooled by temperature-controlled fan
- Controlling by DMX; Master/slave function; stand-alone; CRMX by LumenRadio via USB (optional); QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional)
- Flicker-free projection
- Very high color rendering index (CRI)
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 100 W |
| IP classification: | IP20 |
| Protection class: | Class I |
| Power connection: | Mains input P-Con (blue), mounting version power supply cord with safety plug (provided) |
| Power output: | P-Con (gray), mounting version |
| Lamp type: | LED lamp |
| LED: | 192 x SMD 5730 0,5 W cold white (CW)
192 x SMD 5730 0,5 W warm white (WW) |
| Color temperature: | 2700K - 5700K adjustable |
| Flash rate: | 1 - 20 Hz |
| DMX channels: | 2-1; 2-2; 3-1; 3-2; 4 |
| DMX input: | 1 x 3-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version |
| Cooling: | Temperature-controlled fan |
| Control: | DMX; Master/slave function; stand-alone; CRMX by LumenRadio via USB (optional); QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional) |
| Beam angle: | 120° |
| Beam angle (1/2 peak): | 120° |
| Color rendering index (CRI) more than: | 90 Ra |
| Housing color: | Black |
| Display type: | LCD display |
| Dimensions: | Length: 34,7 cm
Width: 13,8 cm
Height: 21,1 cm |
| Weight: | 3,52 kg |
| Legal specifications |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
