EUROLITE Set 10x LED PR-100/32 Pixel...

EUROLITE Set 10x LED PR-100/32 Pixel DMX Rail + DMX Software

20000807
2 620,48 €



10x DMX-controllable pixel rail with RGB color mixing incl. USB interface and Art-Net interface

EUROLITE LED PR-100/32 Pixel DMX rail

DMX controlled pixel tube with RGB color mixing

  • 96 high-power RGB LEDs (3in1) with wide beam angle
  • 32 individually controllable pixels (illumination units with 3 LED each)
  • Auto, music, master/slave and DMX mode
  • 12 built-in auto and music show programs
  • Stepless color blend, color change and preset colors
  • Electronic dimmer (0-100%)
  • Direct color selection for 17 preset colors
  • DMX and power terminals intelligently designed for easy wiring
  • Control panel with LED display for easy configuration
  • Rugged metal housing with swivel mounting brackets
  • Front cover: black
  • Swivel mounting bracket
  • Mains input and output for power linking up to 8 units
  • LED: 96 x SMD 5050 3in1 TCL RGB (homogenous color mix)
  • Can be operated in 3; 5; 8; 48; 96 CH mode
  • The device is cooled by passive convection
  • Controlling by stand-alone; DMX; Sound to light via Microphone

EUROLITE USB Interface 2x512 DMX/Artnet incl. 64x DMX512 Control Software

USB interface for 2 DMX universes with 3 lighting control softwares

  • USB interface for 2 DMX universes (1024 channels) Pixel Control
  • Incl. 3 x lighting control software for different applications (download)
  • LED PC Control (architectural lighting)
  • DMX Control (show lighting)
  • Pixel Control (pixel mapping and video mixing)
  • Compatible with Windows and Mac OS X (requires Open GL 4.0 at least)
  • Suitable for all RGB and RGBW LED fixtures and LED panels
  • 64 Art-Net universes with 512 channels each on Ethernet
  • 32,768 individual channels or 10,922 RGB pixels
  • High DVI resolution output (1280 x 1024 pixels)
  • Supports touch screen controls
  • Minimum configuration required: Windows / Mac OS, 2 GHz CPU, 8 GB RAM memory, 2 GB RAM graphic card, 500 MB hard disk, 1 USB port (interface dongle), 1 Ethernet port (Art-Net out)
  • Software available for free download at www.eurolite.de
  • Can transmit up to 1024 DMX channels
  • Controlling by DMX
  • The device can be connected via USB to the PC

EUROLITE Art-Net/DMX Node 8 MK2

Art-Net interface for output of 8 universes on XLR

  • Distributes Art-Net data to 8 DMX512 universes (4096 channels)
  • Parallel DMX input possible (1024 channels)
  • 8 optically isolated XLR plugs (3-pin) for DMX output
  • 2 XLR jacks (3-pin) for DMX input
  • Variable data routing capabilities for all DMX outputs
  • 2 x Ethernet port
  • Serial connection possible
  • User-friendly configuration directly at the front panel via 4 operating buttons and alphanumeric LCD screen (2 x 16 characters)
  • LED indication for functions
  • Splitter operation possible
  • Rack installation, 1 U
  • Controlling by ArtNet
  • The device can be connected via RJ-45 (F) mounting version to the PC
  • (19") 48.3 cm rack installation


Weight:23,58 kg
EUROLITE LED PR-100/32 Pixel DMX rail
Power supply:100-240 V AC, 50/60 Hz
Power consumption:30 W
IP classification:IP20
Protection class:Class I
Power connection:Mains input P-Con (blue), mounting version power supply cord with safety plug (provided)
Power output:1 x P-Con (gray), mounting version
Lamp type:LED lamp
LED:96 x SMD 5050 3in1 TCL RGB (homogenous color mix)
Flash rate:20 Hz
DMX channels:3; 5; 8; 48; 96
DMX input:3-pin XLR (M) mounting version
DMX output:3-pin XLR (F) mounting version
Cooling:Passive convection
Control:Stand-alone; DMX; Sound to light via Microphone
Beam angle:120°
Beam angle (1/2 peak):120°
Housing color:Black
Display type:4 digits 7-segment LED display
Dimensions:Length: 99,9 cm
Width: 5,95 cm
Height: 13,2 cm
Weight:2,10 kg
Noise classification:Class 0 (no noise at all)
Legal specifications
Special product:Not designed for household room illumination
Intended use:Show effect lighting
EUROLITE USB Interface 2x512 DMX/Artnet incl. 64x DMX512 Control Software
Power supply:100-240 V AC, 50/60 Hz
5 V DC 1 A
Power connection:Mains input micro USB (F) mounting version power supply cord for USB A mains connection (provided)
DMX channels:Output 1024
DMX output:2 x 3-pin XLR (F) mounting version
Control:DMX
USB port:USB 2.0, Typ Mini USB (F) mounting version
Color:Black
PC connect:Via USB
Dimensions:Width: 7 cm
Depth: 9 cm
Height: 4,5 cm
Weight:180 g
EUROLITE Art-Net/DMX Node 8 MK2
Power supply:100-240 V AC, 50/60 Hz
Power consumption:5 W
Power connection:Mains input P-Con (blue), mounting version power supply cord with safety plug (provided)
DMX input:2 x 3-pin XLR (M) mounting version
DMX output:8 x 3-pin XLR (F) mounting version
Network connection:Protocol: ArtNet 3 via 2x RJ-45 (F) mounting version
Control:ArtNet
PC connect:Via RJ-45 (F) mounting version
Housing design:(19") 48.3 cm rack installation
Dimensions:Width: 48,3 cm
Depth: 17,5 cm
Height: 4,45 cm
Weight:2,40 kg
