Truss light and uplight with bright 3 x 7 W RGB+UV LEDThe flicker-free EUROLITE TL-3 Trusslight is equipped with three 7 Watt 4in1 LEDs each in the colors red, green, blue and UV. It is compact and powerful and therefore very suitable for trussing, stand construction and stage mounting. The TL-3 fits perfectly to the 3-point system ALUTRUSS DECOLOCK DQ3. Also on board are integrated show programs in auto and music mode, direct color selection for 17 colors, dimmer and strobe effect with variably adjustable speed. The trusslight can be used in master/slave mode. Addressing and settings can be done via the integrated control unit with four-digit LED display. You can control the TL-3 either with the included infrared remote control, in standalone mode, via DMX or optionally QuickDMX. Thanks to the IEC mains connections, you can easily connect up to eight devices together.
Variable truss light and uplight with bright 3 x 7 W RGB+UV LED
- Compact and bright - ideal as truss light
- Equipped with 3 x 7 W 4in1 LED in the colors red, green, blue and UV
- Stand-alone, master/slave and DMX mode
- Built-in auto and music show programs
- Direct color selection for 17 preset colors
- Stepless color blend, color change, dimmer and strobe effect
- Supports QuickDMX - the wireless DMX system from Eurolite
- Built-in phantom-powered USB port for QuickDMX, CRMX and WDMX receivers (optional)
- Control panel with LED display for easy configuration
- Convenient wireless control via included IR remote control
- Ideal for booth construction, stages and anywhere trussing is used
- Perfect for ALUTRUSS 3-POINT SYSTEM DECOLOCK DQ3
- M10 threaded insert for suspended installation
- Additional rubber feet protect the device when positioned on the floor
- Mains input and output for power linking up to 8 units
- Can be operated in 3; 4; 4; 8 CH mode
- Controlling by IR remote control (provided); stand-alone; DMX; Master/slave function; Sound to light via Microphone; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
- Preprogrammed in Light´J; LED PC-Control 512; EASY SHOW; LED EASY OPERATOR DELUXE
- Flicker-free projection
- Effect: UV effect; Strobe effect; dimmable
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 15 W |
| Power connection: | Mains input IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Power output: | 1 x Safety contact (F), mounting version |
| Fuse: | F 1 A Fuse replaceable |
| Lamp type: | LED lamp |
| Flash rate: | 1 - 20 Hz |
| DMX channels: | 3; 4; 4; 8 |
| DMX input: | 1 x 3-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version |
| Control: | IR remote control (provided); stand-alone; DMX; Master/slave function; Sound to light via Microphone; Light´J; LED PC-Control 512; EASY SHOW; LED EASY OPERATOR DELUXE; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional) |
| Beam angle: | 16° |
| Beam angle (1/2 peak): | 16° |
| Beam angle (1/10 peak): | 33° |
| Housing color: | Black |
| Dimensions: | Width: 12,2 cm
Depth: 10,8 cm
Height: 11,7 cm |
| Weight: | 890 g |
| Remote control |
| Battery: | 1 x Button cell 3.0 V CR2025 lithium manganese built-in |
| Legal specifications |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
