Suitable Pinspot for PAR-36 6V/30 W lampThe Pinspot T-36 is very well suited for illuminating mirror balls, for entrance or counter areas or simply as basic lighting.Its narrow beam angle makes the projection show a 30-centimetre light circle from a distance of four metres. The use of alternative light sources makes several beam angles possible. Color caps or color foils can easily be placed in front of the T-36.The body of the pinspot is available in black and optionally in silver and can be easily locked in place using the retaining clip.
Pinspot with PAR-36 6V/30W lamp
- Narrow beam angle, at a distance of 4 m there is a projected circle of light with a diameter of 30 cm
- Color caps or color foils can be attached in front of the lens
- For illuminating e.g. mirror balls, entrance or counter areas or as basic illumination
- Low power consumption
- Diverse beam angles are possible when using alternative illuminants
- Locking possibility at the mounting bracket
- Available in silver or black
- Comes in a sales-promoting 4-color carton
- Controlling by plug and play
lamp
- Very high color rendering index (CRI)
| Power supply: | 230 V AC, 50 Hz |
| Power consumption: | Max. 30 W |
| IP classification: | IP20 |
| Protection class: | Class I |
| Suitable lamp: | PAR-36 G53STC |
| Power connection: | Fixed power supply cord with safety plug |
| Cable length: | Approx. 0,9 m |
| Base: | Wires |
| Control: | Plug and play |
| Housing color: | Black |
| Material: | Metal |
| Dimensions: | Length: 16 cm
Width: 15,5 cm
Height: 17 cm |
| Weight: | 1,23 kg |
| Lamp |
| Voltage (lamps): | 6,4 V |
| Nominal wattage: | 30 W |
| Base: | G53STC |
| Lamp type: | Halogen lamp; clear lamp |
| Lamp specification: | Dimmable |
| Beam angle: | 6° |
| Color temperature: | 3000K |
| Color rendering index (CRI) more than: | 95 Ra |
| Shape: | PAR-36 |
| Lamp clamping ring |
| Material: | Metal |
| Color: | Silver |
| Legal specifications |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
