The AX amplifiers are perfect for stereo or bridged mono application and with the onboard two way crossover, will suit virtually any application. The crossover frequency can be set at either 100Hz or 150Hz. Each channel can be assigned to the high, or low, frequency signal. The output from each crossover is also available on 1/4” jack sockets to connect more amplifiers.
Both channels @ 8 ohms RMS | 450 watts |
Both channels @ 4 ohms RMS | 750 watts |
Both channels @ 2 ohms RMS | 990 watts |
Bridged @ 8 ohms RMS | 1500 watts |
Bridged @ 4 ohms RMS | 1950 watts |
Input sensitvity : rated power @ 4 ohms | 0dBu 0.775V |
Distortion THD : 1kHz @ rated power | AX215/AX225 : 0.01% / AX235 : 0.02% |
Frequency response | 20Hz - 20kHz +0/-0.5dB |
Signal to noise ratio : rated power @ 4 ohms | 100dB unweighted |
Input filter | 35Hz 3rd order 18dB/oct |
Crossover | Selectable 100/150Hz 3rd order filter |
Cooling | Twin variable speed fans, back to front airflow |
Protection | Short / open circuit, thermal, ultrasonic & RF protection |
stable into mismatched or reactive loads | |
Output circuit type | AX215 : AB / AX225 : AB+H(2) / AX235 : AB+H(3) |
Power requirements | 230V +/-10% ~ 50/60Hz |
Power consumption @ 230V 1/3power pink noise | AX215 : 4.6A / AX225 : 7A / AX235 : 8.2A |
Connection : Inputs | Combination XLR and jack, Male XLR link socket |
Connection : Outputs | 4 pole industry standard sockets |
Dimensions (wxhxd) | 482mm(19") x 89mm(3.5") x 394mm(15.5") |
Weight (net/shipping) | AX225 : 19.4kg(42.7lb) / 23kg |
