The 1 U flat stereo mixing amplifier EPA-100BT with efficient class D output circuitry is particularly suitable for permanent installations in restaurants, gyms and retail locations which require quick-access music playback control. It provides 2 x 50 watts at 4 ohms and lets you play and control music from multiple sources. Equipped with connections for a microphone and a line-level audio source, it also features a built-in audio player with USB port and memory card slot as well as a Bluetooth receiver for wireless audio streaming directly from your smartphone, tablet or any other Bluetooth-enabled device.
19" mixing amplifier with audio player, Bluetooth and 2 x 50 W power
- 1 U flat stereo mixing amplifier with 2 x 50 watts power
- For quick-access music playback control in restaurants, fitness studios and retail locations
- Built-in audio player with USB port and SD card slot
- Blue backlit LCD screen
- Integrated Bluetooth audio streaming
- Adjustable stereo line input via XLR and RCA jacks
- Adjustable microphone input on the front panel
- Controls for volume, bass and treble
- Signal, clip and power indicators
- Stereo line output via XLR and RCA jacks
- Screw terminals for low-impedance speakers
- Groundlift switch against humming
- Limiter for overload protection
- Efficient class D circuitry
- Low weight and height due to integrated switch mode power supply
- Rack installation, 1 U
- The device is cooled by cooling fan
- (19") 48.3 cm rack installation (provided) 1 U
Audio player
- Bluetooth: Use a operating range up to 10m
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 100 W |
| Output power: | 30 W RMS (8 ohms)
50 W RMS (4 ohms) |
| Power connection: | Mains input IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Frequency range: | 20 - 20000 Hz |
| Cooling: | Cooling fan |
| Circuitry: | Class D |
| Equalizer: | Master: 1 x 2-band tone control stereo |
| Connections: | Input: Microphone via 1 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version)
Input: line via 2 x 3-pin XLR
Input: line via 1 x stereo RCA
Output: line via 2 x 3-pin XLR
Output: line via 1 x stereo RCA
Output: speakers via screw terminal |
| Housing design: | (19") 48.3 cm rack installation (provided) 1 U |
| Dimensions: | Width: 48,3 cm
Depth: 21 cm
Height: 4,45 cm |
| Weight: | 2,59 kg |
| Audio player |
| Audio player: | USB + SD + Bluetooth |
| Format: | WMA; MP3, WAV |
| Carrier frequency: | 2,4 GHz |
| Available storage media: | USB devices/SD cards max. 32GB |
| Range: | 10 m Bluetooth |
