EUROLITE Set 2x Stage Panel 16 + Color Chief + QuickDMX transmitter + 2x receiver

Stage panel set with 2x light effect bar, DMX lighting desk, transmitter and 2x receiver

EUROLITE Stage Panel 16 HCL LED

Light effect bar with RGBAW+UV color mixing, with 5-pin QuickDMX connector

• 16 high-power 12 W RGBAW+UV LEDs (6in1)
• 4 segments for dynamic running lights
• Built-in auto and music show programs
• Direct color selection for 26 preset colors
• Variable color temperature 2700-8000 K
• Stepless color blend, color change, color fade, dimmer and strobe effect
• 4 barn doors to avoid blinding the audience and for protection during transport
• Control panel with LED display for easy configuration
• Convenient wireless control via included IR remote control
• Supports QuickDMX - the wireless DMX system from Eurolite
• Built-in phantom-powered socket for QuickDMX receivers (accessories)
• Swivel mounting bracket
• Mains input and output for power linking up to 8 units
• LED: 16 x high-power 12 W 6in1 HCL RGBWA/UV (homogenous color mix)
• Can be operated in 2; 3; 5; 6; 8; 11; 24; 32 CH mode
• The device is cooled by passive convection
• Controlling by stand-alone; DMX; IR remote control; Sound to light via Microphone; QuickDMX via 5-pin XLR (M) mounting version (optional); Master/slave function
• Preprogrammed in Light´J; LED PC-Control 512; EASY SHOW; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE
• Flicker-free projection
• Effect: Strobe effect; UV effect

EUROLITE DMX LED Color Chief Controller

DMX lighting desk with innovative control concept for LED spotlights

• Easy control of LED spotlights with up to 6 colors, light bars as well as simple lighting effects
• For 8 devices or device groups, each with up to 4 segments
• Each device can occupy up to 30 channels
• Quick and easy programming
• Eurolite KLS systems and LED spotlights already in the library
• Additional fixtures can be configured manually
• 8 color effects directly selectable
• 3 additional channels available per fixture (e.g. for rotations)
• Color wheel selection and simulation
• 24 memory spaces for scenes and chases
• Several chases can be run simultaneously
• USB port for storing program data
• Sound control via audio signal or TAP button
• Master dimming, fade time and run time easily adjustable
• 3-pin XLR connector
• Firmware update via USB
• Desktop console
• Programmable 24 sequencens
• Can transmit up to 240 DMX channels
• Controlling by DMX; Sound to light via RCA (F) mounting version; Sound to light via Microphone
• (19") 48.3 cm rack installation 3 U

EUROLITE QuickDMX Wireless Transmitter

Compact wireless DMX transmitter 2.4 GHz

• User-friendly 3-pin XLR plug (male) with swivel antenna
• Wireless DMX eliminates extensive cabling between DMX controller and the DMX-controlled units in lighting installations
• Due to GFSK modulation with 78 channels, interference-free operation also alongside other QuickDMX transmitters and wireless devices in the 2.4 GHz band (e.g. Wi-Fi and Bluetooth)
• Simultaneous operation of up to 6 transmitters, thus control of 3072 DMX channels (6 DMX universes) possible
• 1 to 512 QuickDMX receivers can be controlled by each transmitter
• Plug & Play: quick and easy setup with one operating button for connecting/disconnecting QuickDMX receivers
• LED indication for functions
• Transceiver, to be used as transmitter or receiver
• Operation via included power adapter
• 2.4 GHz - license-free worldwide
• Can transmit up to 512 DMX channels
• Controlling by QuickDMX built-in; DMX
• Use a operating range up to 400m

EUROLITE QuickDMX Wireless receiver phantom-power

Compact wireless DMX receiver 2.4 GHz, phantom powered

• User-friendly 5-pin XLR plug (female) with swivel antenna
• Wireless DMX eliminates extensive cabling between DMX controller and the DMX-controlled units in lighting installations
• Due to GFSK modulation with 78 channels, interference-free operation also alongside other QuickDMX receivers and wireless devices in the 2.4 GHz band (e.g. Wi-Fi and Bluetooth)
• 1 to 512 QuickDMX receivers can be controlled by each transmitter
• Plug & Play: quick and easy setup with one operating button for connecting/disconnecting QuickDMX receivers
• LED indication for functions
• Transceiver, to be used as transmitter or receiver
• Requires 5 V phantom power for operation
• 2.4 GHz - license-free worldwide
• Can receive and process up to 512 DMX channels
• Controlling by DMX; QuickDMX built-in
• Use a operating range up to 400m
