2-channel DJ mixer including 2x DJ player for CD, USB and SD
OMNITRONIC PM-222 2-Channel DJ Mixer
2-channel DJ mixer
- 2 input channels with gain control, 2-way equalizer and phono/line switching
- DJ microphone input with separate level control
- Pre-fader listening (CUE) to the stereo input channels via adjustable headphone output, with cue mix control
- Replaceable crossfader for crossfading between both channels
- 6-digit stereo LED level meter and master level control
- Inputs: 4 x line and 2 x phono (stereo RCA), DJ microphone and headphones (6.3 mm jack)
- Outputs: master and record (stereo RCA)
- Desktop console housing
OMNITRONIC XMT-1400 Tabletop CD Player
DJ player for CD, USB and SD
- Tabletop player with scratch function for DJs
- Audio CD, CD-R, CD-RW, MP3 CD
- USB port for storage media and portable players
- SD(HC) card slot
- Anti-shock RAM buffer memory
- Alphanumeric VFD supports CD text and ID3 tags (artist and title name)
- Touch-sensitive scratch jog dial with mode selector: pitch bend, scratch, fast or frame search
- Reverse run
- Brake effect (as with analog turntables)
- Comfortable track selection via 10-digit numerical track input
- Folder navigation
- Search buttons for fast forward and reverse
- Pitch adjustment ±4 %, ±8 %, ±12 %, ±16 %
- Pitch bend via jog dial or separate buttons
- Manual beat counter
- Instant start and cue function with preview
- Double loop/reloop function
- Single or continuous play
- Repeat functions
- Title programming
- Indication of elapsed time, remain time (MP3 files) or total remain time (audio CD)
- Bargraph display
- Pitch adjustment is displayed in %
- Large play/pause and cue buttons with color illumination
- Desktop console housing
| Weight: | 6,60 kg |
| OMNITRONIC PM-222 2-Channel DJ Mixer |
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 30,00 W |
| Protection class: | Class II |
| Power connection: | Mains input C8 "figure 8" mounting version power supply cord with Euro plug (provided) |
| Frequency range: | 20 - 20000 Hz |
| S/N ratio: | >70 dB |
| THD: | <0,025 % at 1 kHz |
| Impedance: | Input Microphone: 47 kOhm
Input line: 47 kOhm
Input phono: 47 kOhm |
| Gain: | Input: variable |
| Control elements: | Power switch, source selector, Crossfader |
| Status LED: | Master level meter, power |
| Connections: | Input: Microphone via 1 x 6.3 mm jack socket (mono) mounting version
Input: line via 4 x stereo RCA
Input: phono via 2 x stereo RCA
Output: master via 1 x stereo RCA
Output: rec. via 1 x stereo RCA
Output: headphones via 1 x 6.3 mm jack socket (stereo) mounting version |
| Channels: | Input chanel: 2 x stereo with Line-Line-Phono switch via RCA, channel control via fader, 2-band tone control EQ, gain control,
Microphon chanal: 1 x mono via Plug 6,3mm/3,5mm (Jack), channel control via Rotary dial, Cue-mix-function,
Master output: 1 x stereo via RCA, channel control via Rotary dial
Headphones output: 1 x stereo via Plug 6,3mm/3,5mm (Jack), channel control via Rotary dial |
| Max. level: | Output: master +19 dBu |
| Housing design: | Desktop console housing |
| Dimensions: | Width: 19 cm
Depth: 26 cm
Height: 13,7 cm |
| Weight: | 2,00 kg |
| OMNITRONIC XMT-1400 Tabletop CD Player |
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 12 W |
| Power connection: | Mains input C8 "figure 8" mounting version power supply cord with Euro plug (provided) |
| Frequency range: | 20 - 20000 Hz |
| S/N ratio: | >86 dB |
| THD: | <0,01 % at 1 kHz |
| Audio player: | USB + SD + CD player pitch Anti-shock Seamless loop |
| CD player drive: | Drawer-Single CD drive |
| Display: | CD-DA play time remaining , play time elapsed , total play time remaining , Bargraph; MP3 play time remaining , play time elapsed , Bargraph , ID3-Tags |
| Control elements: | Power switch, source selector |
| Connections: | Output: line via 1 x stereo RCA 2 V |
| Format: | CD, CD-R, CD-RW, CD-DA, MP3 |
| Frame accuracy: | 1/75 s |
| Available storage media: | USB devices/SD cards max. 32GB (FAT 16/32) |
| Pitch range: | ±4%, ±8%, ±12%, ±16% |
| Material: | Plastic |
| Housing design: | Desktop console housing |
| Dimensions: | Width: 23 cm
Depth: 31 cm
Height: 12 cm |
| Weight: | 2,30 kg |
