70064820
155,87 €


One DMX-line is partitioned into six lines with this splitter. Due to the fact, that all outputs are seperated galvanically, one broken line will not cause a blackout. When a lighting performance without any disturbance is aspired, then this DMX Split is a must-have.

Splitter with 6 galvanically isolated outputs, 3-pin & 5-pin XLR sockets

  • DMX splitter for splitting one DMX input signal to 6 DMX outputs
  • Input and outputs galvanically isolated
  • Connections XLR 3-pin and 5-pin
  • Every DMX output with independent driver and data indicator
  • Input and outputs with a set of respective power supply and internal fuse
  • Rack mounting


Power supply:230 V AC, 50 Hz
Power consumption:35 W
Power connection:Fixed power supply cord with safety plug
DMX input:1 x 3-pin XLR (M) mounting version
1 x 5-pin XLR (M) mounting version
DMX output:6 x 3-pin XLR (F) mounting version Separate (galvanic)
6 x 5-pin XLR (F) mounting version Separate (galvanic)
1 x 5-pin XLR (F) mounting version Bypass
1 x 3-pin XLR (F) mounting version Bypass
Control elements:Bypass/terminating resistor Schalter, power switch
Dimensions:Width: 48,3 cm
Depth: 20 cm
Height: 4,45 cm
Weight:3,23 kg
