- Built-in 100v/70v transformer
- Superior sound quality speaker for music & speech
- In-ceiling type loudspeaker
- 6” +1.5” coaxial plastic speaker unit
- Power taps 2.5W, 5W, 10W & 20W @100V
- Metal grille & ABS baffle
- Paint in white color
- Flush mount easy & secure installation
The T-206A is a ceiling speaker built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers.
The built-in 6”+1.5” coaxial plastic speaker driver is designed of wide frequency response 70-20kHz, the multiple power taps 2.5W, 5W, 10W & 20W are helpful for different applications varies from room size and ambient noise surroundings. The metal grille and ABS baffle are painted in attractive white color. Its flush mount type makes the easy and secure installation.
It is ideal choice for industrial and commercial applications in hotel, school, office and factory where background music and paging is needed.
Model |
T-206A |
Power Taps @100V |
2.5W, 5W, 10W, 20W |
Power Taps @70V |
1.25W, 2.5W, 5W, 10W |
Impedance |
Black: Com Blue:4KΩ Red:2KΩ Green:1KΩ White:500Ω |
SPL(1W/1M) |
92dB |
Max. SPL (Rated W/1M) |
105dB |
Frequency Response (-10dB) |
70-20KHz |
Finish |
Baffle: ABS, White Grille: Steel, White |
Speaker Driver |
6" x 1 1.5" x 1 |
Cutout Size |
208mm |
Dimensions |
232 x 107mm |
Weight |
1.2Kg |
Mounting |
Flush-mount dog ears |
