Mixer for microphone and line sourcesThe perfect tool for your karaoke party: With the Omnitronic EM-260B Entertainment Mixer you mix 3 microphone and 3 line sources to one stereo output - in an very simple way. Installing the mixer is easy as well, thanks to the small dimensions you are flexible.Design clearly arrangedEven if you are a beginner, you can operate the mixer very easily. As it is clearly structured, you won't get lost. Each channel has a clip LED. The microphone inputs show optional 12 V phantom power. The unit is perfectly suited for bar, restaurant or club house installation.Effects an recording sessionsWith the FX send/return (with FX level control) you can cut in effects to support your voice. Record singing sessions by using the record output.
6-channel microphone/line mixer
- 6 inputs (3 x mic/line and 3 x line) for mixing to 1 stereo output
- Ideal e.g. for karaoke when microphones need to mixed with CDs
- 3 mono input channels mic/line (XLR, bal.), switchable
- 3 stereo line input channels (RCA)
- Clip LED for each microphone channel
- Each microphone input with optional 12 V phantom power
- FX send/return with FX level control
- Stereo master out (6.3 mm jack) with 2-band equalizer (highs and lows) and level control
- Stereo record output (RCA)
- (19") 48.3 cm rack installation 1 U
| Power supply: |
115/230 V AC, 50/60 Hz |
| Power consumption: |
35 W |
| Protection class: |
Class I |
| Power connection: |
Mains input IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Frequency range: |
20 - 20000 Hz |
| Phantom power: |
12 V DC |
| Housing color: |
Black |
| Control elements: |
Phantom power switch, power switch, FX send/returne control |
| Status LED: |
Power, clip |
| Connections: |
Input: mic/line via 3 x 3-pin XLR
Input: line via 3 x stereo RCA
Input: FX via 2 x 6.3 mm jack socket (mono) mounting version
Output: rec. via 1 x stereo RCA
Output: master via 2 x 6.3 mm jack socket (mono) mounting version
Output: FX via 1 x 6.3 mm jack socket (stereo) mounting version |
| Channels: |
Input chanel: 3 x stereo via RCA, channel control via Rotary dial, 2-band tone control EQ 100Hz/10kHz
Microphon chanal: 3 x mono with Mic-line switch via XLR, channel control via Rotary dial
Master output: 1 x stereo via Plug 6,3mm/3,5mm (Jack), channel control via Rotary dial |
| Max. level: |
Input: Microphone +14 dB
Input: line +24 dB |
| Material: |
Metal |
| Color: |
Silver |
| Housing design: |
(19") 48.3 cm rack installation 1 U |
| Dimensions: |
Width: 48,3 cm
Depth: 12,3 cm
Height: 4,45 cm |
| Weight: |
2,30 kg |
