Wireless DMX system 2.4 GHz - two transceivers with W-DMX unit in one 19" housing
- Two W-DMX transceivers by Wireless Solution in one housing
- Switching between transmitter and receiver
- Compatible with Wireless Solution W-DMX systems
- Wireless DMX eliminates extensive cabling between DMX controller and the DMX-controlled units in lighting installations
- AFHSS technology ensures interference-free operation also alongside other DMX transmitters and wireless devices in the 2.4 GHz band (e.g. Wi-Fi and Bluetooth)
- 1 to 512 receivers can be controlled by each transmitter
- Simultaneous operation of up to 6 transmitters, thus control of 6 DMX universes (3072 DMX channels) possible
- Plug & play: quick and easy setup with one operating button
- LED indication for operation and functions
- DMX input and output, 3-pin XLR
- 2.4 GHz - license-free worldwide
- 483 mm device (19")
- Rack installation, 1 U
- Can receive and process up to 1024 DMX channels
- Can transmit up to 1024 DMX channels
- Controlling by DMX; W-DMX by wireless solution built-in
- Use a operating range up to 500m with line of sight
- (19") 48.3 cm rack installation 1 U
| Power supply: | 230 V AC, 50 Hz |
| Power consumption: | 4 W |
| IP classification: | IP20 |
| Power connection: | Mains input P-Con (blue), mounting version power supply cord with safety plug (provided) |
| DMX channels: | Input 1024
Output 1024 |
| DMX input: | 2 x 3-pin XLR (M) mounting version |
| DMX output: | 2 x 3-pin XLR (F) mounting version |
| Control: | DMX; W-DMX by wireless solution built-in |
| Frequency band: | 2.4 GHz |
| Carrier frequency: | 2,4 GHz |
| Modulation: | AFHSS |
| Latency: | < 5 ms |
| Parallel mode: | Max. 6 transmitter |
| Range: | 500 m with line of sight |
| Color: | Black |
| Housing design: | (19") 48.3 cm rack installation 1 U |
| Dimensions: | Width: 48,3 cm
Depth: 16 cm
Height: 4,45 cm |
| Weight: | 1,98 kg |
