Mini beam with 60 W COB LED, RGBW color mixing and hypno ring in 4 segments
- Beam effect with a 60 W COB LED in RGBW colors and hypno ring with altogether 12 RGB SMD LEDs
- Stepless color blend, color change, preset colors, dimmer and strobe effect
- Built-in programs
- LED hypno ring with stepless RGB color mixture - each color and each segment can be controlled individually
- Compact lightweight
- Positioning within 540° PAN and 210° TILT
- Exact positioning via 16-bit PAN/TILT movement resolution
- Stand-alone, master/slave and DMX mode
- Control panel with LED display for easy configuration
- LED: 12 x SMD 3in1 TCL RGB (homogenous color mix)
- LED: 1 x COB (chip-on-board) 60 W 4in1 QCL RGBW (homogenous color mix)
- Can be operated in 16; 21; 23 CH mode
- The device is cooled by cooling fan
- Controlling by stand-alone; Sound to light via Microphone
- Preprogrammed in Light´J; LED PC-Control 512
- Flicker-free projection
- Effect: Single Beam
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 70 W |
| IP classification: | IP20 |
| Power connection: | Mains input IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Lamp type: | LED lamp |
| LED: | 12 x SMD 3in1 TCL RGB (homogenous color mix)
1 x COB (chip-on-board) 60 W 4in1 QCL RGBW (homogenous color mix) |
| Max. TILT movement: | Exact positioning (16 bit resolution) 210° |
| Max. PAN movement: | Exact positioning (16 bit resolution) 540° |
| Flash rate: | 0 - 20 Hz |
| DMX channels: | 16; 21; 23 |
| DMX input: | 1 x 3-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version |
| Cooling: | Cooling fan |
| Control: | Stand-alone; Sound to light via Microphone; Light´J; LED PC-Control 512 |
| Beam angle: | 8° |
| Beam angle (1/2 peak): | 8° |
| Housing color: | Black |
| Dimensions: | Width: 17 cm
Depth: 16 cm
Height: 24,5 cm |
| Weight: | 2,92 kg |
| Legal specifications |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
