70064826
235,95 €




Splitter with 8 galvanically isolated outputs, 3/5-pin & QuickDMX XLR sockets

  • DMX splitter for splitting one DMX input signal to 8 DMX outputs
  • Connections: 1 x DMX input, 1 x DMX feed-through output, 8 x DMX output
  • Additional QuickDMX input for wireless reception of DMX signals
  • Supports RDM for bidirectional communication over the DMX line
  • Switchable filter mode allows all RDM data to be filtered out in order to prevent problems when using fixtures intolerant of RDM
  • Input and outputs XLR 3-pin and 5-pin each
  • Input and outputs galvanically isolated
  • Each DMX output with independent driver and status indicators
  • Input and outputs with a set of respective power supply and internal fuse
  • Switchable termination resistor
  • Rack mounting
  • Controlling by QuickDMX via 5-pin XLR (M) mounting version (optional); RDM


Power supply:100-240 V AC, 50/60 Hz
Power consumption:5 W
Power connection:Mains input IEC connector (M) mounting version power supply cord with safety plug (provided)
DMX input:1 x 3-pin XLR (M) mounting version
1 x 5-pin XLR (M) mounting version
DMX output:8 x 3-pin XLR (F) mounting version Separate (galvanic)
8 x 5-pin XLR (F) mounting version Separate (galvanic)
1 x 5-pin XLR (F) mounting version Bypass
1 x 3-pin XLR (F) mounting version Bypass
Control:QuickDMX via 5-pin XLR (M) mounting version (optional); RDM
Control elements:Bypass/terminating resistor Schalter, power switch
Dimensions:Width: 48,3 cm
Depth: 14,5 cm
Height: 4,45 cm
Weight:2,20 kg
